Plant Facilities
Plant Facilities
ACE CNC TURNING CENTER ( Model- Jobber LM )
- Maximum turning diameter 290 mm
- Maximum turning length 400 mm
- Chuck Size 200 mm
- Spindle Power (15 minutes rating) 11 kW
ACE CNC TURNING CENTER ( Model-Jobber LM-300 )
- Control FANUC
- Chuck Size 8 Inch
- Station Turret 8
- Hydrolic Drill - 4
- Tool Eye Setting
BFW VMC (Vertical Machining Center) ( Model- MCV-850)
- Stroke X, Y & Z axes 800 / 450 / 500MM
- Table size 1000 mm x 450 mm
- Spindle face to table top 175 – 675 MM
- Spindle speed 80 – 8000 RPM
- Rapid traverse X / Y / Z m / min 30 / 30 / 30
- Guideways Type LM
MNTR ( Model- 3 ESHT )
- Stroke X, Y & Z axes 800 / 450 / 500MM
- Table size 1370 mm x 305 mm
- Spindle hose to table 175 – 675 MM
- Spindle speed 80 – 5440 RPM
- Main spindle taper hole R8 or NT 30
- Ram travel 380 mm
Automatic Bandsaw Machine ( Model- ITL-210-LMGA)
- Size/Dimension 2000 x 2000 x 1850 mm
- Brand ITL
- Round Cutting Capacity 210 mm
- Square Cutting Capacity 210 mm
- Min. Cutting Speed 20 m/min
Drill Machine ( Model- )
- Max Drill Depth 40-50 mm
- Brand Jisko
- Max Hole Size 55 mm
- Weight 800 Kg
- No Load Speed 275-550
List of Machines
100% customer satisfaction is what drives our Quality Policy
ACE CNC TURNING CENTER - (05 Nos.)
JIKSO SPM MACHINE (01 Nos.)
BFW VMC Model-MCV-850 (01Nos.)
MNTR MILLING MACHINE (01 Nos.)
BEND SAW MACHINE (01 Nos.)
Lath 6 ft. (01 No's)
